參數Parameter

尺寸 Diameter

公差 Tolerance

單位Unit

長度 Length

1~2000

±0.2

mm

外經 OD

0.2~6

±0.03

內徑 ID

0.06~5

±0.03

方形毛細管 Square capillary

參數Parameter

尺寸 Diameter

公差 Tolerance

單位Unit

長度 Length

1~2000

±0.2

mm

寬度 Width

0.3x0.3~6x6

±0.03

內徑 ID

0.1x0.1~5x5

±0.03

異型毛細管/棒  Shaped Capillary Tube & Rod

形狀

Shape

錐形管、D形管、橢圓管、梯形管、六邊形管、三角型管、V型棒、U型棒

Conical tube, D-shaped tube, Elliptical tube, Trapezoidal tube, Hexagonal tube, Triangular tube, V-shaped rod, U-shaped rod,

孔徑

Aperture

多孔（雙孔、四孔、六孔，七孔，八孔，雙排三孔）、橢圓孔、矩形、正方形、三角形，偏心孔、D型孔

Multi-hole (double holes, four holes, six holes, seven holes, eight holes, double row three holes), elliptical, rectangle, square, triangle, eccentric, D-shaped

羥基含量

Hydroxyl group

＜10ppm

材料 Material

石英玻璃

Quartz glass

說明 Specification

其他尺寸及公差可按客戶要求生產

Other dimensions and tolerances can be manufactured according to customer requirements
